Technical data COBRA Mill 58
| X;Y;Z axis stroke | 00 x 200 x 100 mm |
| A axis stroke | +/- 30° |
| B axis stroke | 360° |
| Feed rate Max. | 5000 mm/min |
| Position feed Max. | 8000 mm/min |
| Repeatability | 0,009 mm |
| Min. setting unit | 0,001 mm |
| Tool-length sensor | +/- 0,005 mm |
| Table dimension | 340 x 230 mm |
| Distance Table - Spindle | 170 mm |
| Centre Distance B axis | 65 mm |
| AC Servomotors | 200 Watt |
| AC Servodrivers | 200 Watt |
| Ronde holder | 100 mm |
| Clamping system | Quick Ring |
| HF Spindle Jaeger | 60000 U/min/ 230 Watt |
| Option HF Spindle | 60000 U/min/ 900 Watt |
| Tool Ø max. | (Opt. 6,0 mm) 3,0 mm |
| Number of tools | (Opt. 16 Stück) 8 pcs |
| Power connection | +/- 5% 230 V |
| Max. connected load | 4,3 kVA |
| Compressed air connection | 320 l/min at 6,5 bar |
| Preparation for wet milling | Innertank with connections |
| Dimension W;D;H | 770 x 800 x 1850 mm |
| Footpring with tank | 1150 x 900 x 1850 mm |
| Weight | 400 kg |
| Controller: | |
| OSAI/MB 10/510i HSM | |
| Visualisation PC Software | |
| 5 axis simultaneous | |
| Tool correction | |
| 40 MB working memory | |
| OS Wire I/O Board | |
| Network | |
| Teleservice | |
| 10 Work coordinates | |
| SMS Worker information | |
| Wet-setup: | |
| 1 large filter | |
| Flow rate detection | |
| Recognize of filter condition |
